    Tone gear: the superb skills from design to manufacturing

    2023.12.28


    1. Introduction



    As an important transmission component, cone gear has a wide range of applications in the field of mechanical engineering. Its unique design and manufacturing technologies have significant advantages in conical gear in terms of transmitting torque, changing speed, and changing the direction of the transmission direction. This article will explore the design and manufacturing technology of cone gear.



    2.cone gear design

    The design of the cone gear mainly includes the following steps:



    Clear design requirements: First of all, we need to clarify the design requirements of cone gears, including transmission power, torque, speed, spatial restrictions and environmental conditions.



    Select the right type and parameter: According to the design requirements, select the appropriate cone gear type, such as straight tooth cone gear, oblique tooth cone gear, etc. At the same time, determine the appropriate parameters such as cone, teeth, and mold numbers.



    Design tooth shape and parameters: According to the working principle and strength requirements of the gear, design the appropriate tooth shape and parameters, including the width of the tooth surface, the height of the tooth, and the radius radius of the top of the tooth.



    Perform intensity school verification: According to the designed cone gear parameters, the strength school verification is performed to ensure that the gear has sufficient strength and life under the expected working conditions.



    Optimized design: Based on the results of the strength of the strength, the design is optimized to improve the performance and life of the cone gear.



    Set up design drawings and files: organize the entire design process into complete design drawings and files for subsequent manufacturing and application.





    3.cone gear manufacturing technology



    The manufacturing of cone gears mainly includes the following processes:



    Material selection: According to the design requirements and the environment, choose the appropriate materials, such as cast iron, casting steel, forging steel.



    Rough preparation: Prepare the rough according to the designed cone gear parameter. For casting blanks, it is necessary to carry out processes such as shapes and pouring; for forging rough, forging, heat treatment and other processes are required.



    Cutting processing: Use the cutting machine to cut the blank to form the basic contour of the cone gear. This step is the key step of making cone gears, which requires accurately controlling the processing parameters of the machine tools and the selection of tools.



    Heat treatment: In order to improve the mechanical properties of the gear and the service life, the heat treatment process is required, such as quenching and recovery. Thermal treatment can refine the grain structure of the gear to improve its hardness and abrasion resistance.



    Foot surface processing: fine processing of the gear surface of the cone gear to obtain accurate teeth and parameters. This step can adopt processing methods such as grinding and grinding.



    Inspection and assembly: Strict inspection of the cone gear completed by manufacturing to ensure that the parameters of its parameters meet the design requirements. Then assemble, install the gear to the transmission system, and test the performance.



    Surface treatment: In order to improve the corrosion resistance and abrasion resistance of the gear, surface treatment can be performed, such as spraying, carburizing quenching and other processes.



    Organize the manufacturing file: organize the entire manufacturing process into a complete manufacturing file for subsequent quality control and traceability.





    4. the application of the gear



    As an important drive component, cone gear has a wide range of applications in many areas:



    Automotive industry: Tone gear plays a key role in automotive transmission and rear axle transmission system to achieve power transmission and transmission.



    Constitutional machinery: In construction machinery such as excavators and loaders, the gear gear is used to drive working devices and walking mechanisms to achieve efficient and stable transmission.



    Aviation Industry: In the landing gear and engine transmission system of aircraft and helicopters, cone gears are used to accurately transmit torque and change the direction of the transmission.



    Agricultural Machinery: In agricultural machinery such as tractors and harvesters, cone gear is used to drive agricultural machinery and improve operating efficiency and performance.



    Industrial transmission system: In various industrial transmission equipment, cone gear is used to transmit power and change the direction of transmission, and is widely used in the fields of mines, metallurgy, chemical industry and other fields.



    Instrument and instrument: In some high -precision instruments and instruments, the gear gear is used to achieve accurate transmission and positioning.



    Shipping industry: In the ship promotion system and rudder system, the gear gear is used to transfer torque and change the direction of the transmission to ensure the stable navigation of the ship.



    Sports equipment: In some sports equipment that requires high -precision transmission, such as bicycles, gliding machines, etc., the gear gear is also widely used.



    Entertainment equipment: In some large amusement facilities in the playground, the gear gear is also used for power transmission and transmission. Through the above application examples, we can see that cone gear plays an important role in various fields. Its unique design and manufacturing technologies have significant advantages in conical gear in terms of transmitting torque, changing speed, and changing the direction of the transmission direction. With the continuous advancement of technology and the continuous improvement of application needs, the design and manufacturing technology of cone gear will also continue to develop and improve. In the future, we look forward to seeing more efficient, reliable, and precise conical gear applications in more fields.
